VFN 2 Way Ball Valve

Application

VFN Two Way Sanitary Ball Valve has a full port design to reduce turbulence and pressure drop through the valve. The hygienic design is widely used in the field of food processing, beverages, fruit juices, wine.

Technical Specification

Material: SS304 or SS316L

Seat Gasket: PTFE

Operating pressure: Max. 800kPa(8 bar)/ 115 psi

Temperature range: -10°C to 120°C

Actuator

Air pressure: 4-7 Bar

Temperature range: -25°C to 120°C

Standard Design

· Connection: Tri Clamp, Male

· Stanard: 3A, SMS, DIN

· Ball Core: T port or L Port

· Operating : Manual, Pneumatic Actuator, Electric Actuator

  with or without position sensor and solenoid valve
